General
Total Fuel Capacity 13 gallons
Drive Tires 24″ x 12″-12″
Caster Tires 13″ x 6.5″-6″
Seat 4-point iso-mounted mid-back mounted on operator-suspension platform
Drive System
Drive System Type Hydro-Gear ZT5400 Transaxle. Two-Speed
Pumps Internal Pump: 16 cc
Motors Internal Motor: 21 cc
Forward Ground Speed 16 mph (high-speed)

12 mph (low-speed)
Reverse Ground Speed 8 mph (high-speed)

5 mph (low-speed)
Parking Brake Foot-operated pedal
Deck
Cutting Widths 61″ and 72″
Type Velocity Plus™
Cutting Height 1.25″ to 5″ in .25″ increments
Deck Lift Adjustable foot-operated pedal
Construction Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles.
Spindles Cast-iron housing with tapered roller bearings.
