SINGLE SPINDLE HEAVY DUTY BRUSH CUTTER HD-60

Description

Bush-Whacker’s heavy duty single-spindle cutters are great for small areas of grass and small brush. It’s truly a great cut for your money. The Bush-Whacker units come standard with stump-jumpers and deck-rings, and when combined with 120HP gear boxes, you will be hard pressed to find a better value on the market today.

Specifications:

Gearboxes – 120 HP, 540 RPM Base Mounted. Malleable housing, forgedalloy steel; carburized and hardened gears and shafts; 1 3/8” – 6 spline input shaft, tapered bearings.

DRIVE SHAFTS – CATEGORY 4 – Made from the finest quality propeller shaft materials and needle bearing universal joints.

SLIP CLUTCH – Heavy duty spring-type adjustment with four friction discs.

BLADES – 1/2” by 3 1/2” material, alloy spring steel and airlift design that are free swinging when encountering obstructions. Blade tip speed: 16,450FPM

WHEELS – Heavy duty 3–point hitch: with tapered bearings and a 4” by 8” laminated puncture-proof tire.

DECK – 10 Gauge Smooth top deck for easy cleaning.

DECK RINGS – Standard

DIMENSIONS
Cutting height: adjustable from 1” to 9”
Overall width: 64.5”
Overall length: 86.5”
Transportation Width: 76”
Transportation Length: 70”

WEIGHT – 729 lbs

QUICK HITCH ADAPTABLE – CAT1

SIDE SKIRTS – 1/4” MATERIAL – Shaped to fit the sides of cutter.

RECOMMENDED PTO HP – 25HP

RUBBER GUARDS – Single Row Chain Guards optional.

STUMP JUMPER – Standard
